Phatsongwifi
Đài Loan Thương hiệu: EnGenius

Thiết bị phát sóng wifi EnGenius ECW526 - Cloud Managed Wi-Fi 7 2x2x2 Indoor Access Point

Hàng mới 100%
Giá: Liên hệ
Tình trạng
Hàng chính hãng, có CO CQ đầy đủ
Part Number
ECW526
Kho hàng
Liên hệ
Mua nhiều
Khách hàng cần mua số lượng vui lòng liên hệ 0396827937 - 0396827937 - 0901188385 để có giá tốt.
Mô tả

EnGenius Cloud Managed Wi-Fi 7 2x2x2 Access Point ECW526 supports tri-concurrent 802.11be Wi-Fi 7 architecture, delivering supercharged speeds up to5,800 Mbps on 6 GHz, 2,900 Mbps (5 GHz), and up to 720 Mbps (2.4 GHz). With WPA3 & WPA2-AES authentication support, remote monitoring & troubleshooting, and Mesh Wireless Support for optimized signal quality, it's easy to set up and manage an unlimited number of APs with the EnGenius Cloud App.

Yêu cầu báo giá
Vận chuyển

Giao hàng toàn quốc. Chúng tôi sử dụng các dịch vụ giao hàng và thanh toán tại nhà (COD) của Giaohangtietkiem, Viettel Post, GHN và những dịch vụ khác để giao hàng đến quý khách hàng trong thời gian sớm nhất.

Review Xem tại đây
Bán hàng Mr. Đức, Mr. Thành, Mr. Quan, Mr. Thịnh, Mr. Vinh

Product Highlight

EnGenius Cloud Managed Wi-Fi 7 2x2x2 Access Point ECW526 supports tri-concurrent 802.11be Wi-Fi 7 architecture, delivering supercharged speeds up to5,800 Mbps on 6 GHz, 2,900 Mbps (5 GHz), and up to 720 Mbps (2.4 GHz). With WPA3 & WPA2-AES authentication support, remote monitoring & troubleshooting, and Mesh Wireless Support for optimized signal quality, it's easy to set up and manage an unlimited number of APs with the EnGenius Cloud App.

  • Tri- concurrent 802.11be Wi-Fi 7 architecture & backward-compatible
  • Supercharged speeds up to 5,800 Mbps on 6 GHz, 2,900 Mbps (5 GHz) & up to720 Mbps (2.4 GHz)
  • 10 GbE realizes greater throughput and supports 802.3at and 60W PoE injector input for flexible installation over 100 meters (328 feet)
  • WPA3 & WPA2-AES authentication support
  • Cloud Managed with AP & Mesh mode
  • Quick-scan device register & configuration and remote monitoring & troubleshooting
  • Cloud manage an unlimited number of APs from anywhere with the EnGenius Cloud App
  • Mesh Wireless Support simplifies setup, optimizes signals & self-heals

Technical Specifications

Standards

IEEE 802.11be on 2.4 GHz
IEEE 802.11be on 5 GHz
IEEE 802.11be on 6 GHz
Backward compatible with 802.11a/b/g/n/ac/ax

Antenna

2 x 2.4 GHz: 5 dBi(Integrated Omni-Directional)
2 x 5 GHz: 6 dBi(Integrated Omni-Directional)
2 x 6 GHz: 5 dBi(Integrated Omni-Directional)

Physical Interface

1 x 10GE Port (PoE+)
1 x DC Jack
1 x Reset Button

LED Indicators

1 x Multi-color LED

Power Source

Power-over-Ethernet: 802.3at Input 12VDC /2A Power Adapter

Maximum Power Consumption

18W

Wireless & Radio Specifications

Operating Frequency

Tri-Radio Concurrent 2.4 GHz & 5 GHz & 6GHz

Operation Modes

AP, AP Mesh, Mesh

Frequency Radio

2.4 GHz: 2400 MHz ~ 2482 MHz 5 GHz: 5150 MHz ~ 5250 MHz, 5250 MHz ~ 5350 MHz, 5470 MHz ~ 5725 MHz, 5725 MHz ~ 5850 MHz 6GHz: 5925-7125MHz

Transmit Power

Up to 25 dBm on 2.4 GHz
Up to 24 dBm on 5 GHz
Up to 24 dBm on 6 GHz
(Maximum power is limited by regulatory domain)

Tx Beamforming (TxBF)

Radio Chains/Spatial Stream

2 × 2:2

SU-MIMO

Two(2) spatial stream Single User (SU) MIMO for up to 720 Mbps wireless data rate with VHT40 bandwidth to a 2×2 wireless device under the 2.4GHz radio. Two(2) spatial stream Single User (SU) MIMO for up to 2,900 Mbps wireless data rate with HE160 to a 2×2 wireless device under the 5GHz radio. Two(2) spatial stream Single User (SU) MIMO for up to 5,800 Mbps wireless data rate with HE320 to a 2×2 wireless device under the 6GHz radio.

MU-MIMO

Two(2) spatial stream MU-MIMO for up to 720 Mbps wireless data rate with VHT40 bandwidth to a 2×2 wireless device under the 2.4GHz radio. Two(2) spatial stream MU-MIMO for up to 2,900 Mbps wireless data rate with HE160 to a 2×2 wireless device under the 5GHz radio simultaneously. Two(2) spatial stream MU-MIMO for up to 5,800 Mbps wireless data rate with HE320 to a 2×2 wireless device under the 6GHz radio simultaneously.

Supported Data Rates (Mbps):

802.11be: 2.4 GHz: Max 720 (MCS0 to MCS11, NSS = 1 to 4) 5 GHz: Max 2,900 (MCS0 to MSC11, NSS = 1 to 4) 6 GHZ: Max 5,800 (MCS0 to MSC13, NSS = 1 to 4) 802.11ax: 2.4 GHz: 9 to 1,148 (MCS0 to MCS11, NSS = 1 to 4) 5 GHz: 18 to 2,400 (MCS0 to MSC11, NSS = 1 to 4) 6 GHZ: 18 to 4,800 (MCS0 to MSC13, NSS = 1 to 4) 802.11b: 1, 2, 5.5, 11 802.11a/g: 6, 9, 12, 18, 36, 48, 54 802.11n: 6.5 to 600 (MCS0 to MCS31) 802.11ac: 6.5 to 1,733 (MCS0 to MCS9, NSS = 1 to 4)

Supported Radio Technologies

802.11be/ax: Orthogonal Frequency Division Multiple Access(OFDMA) 802.11a/g/n/ac: Orthogonal Frequency Division Multiple (OFDM) 802.11b: Direct-sequence spread-spectrum (DSSS)

Channelization

802.11be supports high efficiency throughput (HE) —HE 20/40/80/160/320 MHz 802.11ax supports high efficiency throughput (HE) —HE 20/40/80/160 MHz 802.11ac supports very high throughput (VHT) —VHT 20/40/80 MHz 802.11n supports high throughput (HT) —HT 20/40 MHz 802.11n supports high throughput under the 2.4GHz radio –HT40 MHz (256- QAM) 802.11n/ac/ax packet aggregation: A-MPDU, A-SPDU

Supported Modulation

802.11ax: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM, 4096-QAM 802.11ax: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM 802.11ac: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM 802.11a/g/n: BPSK, QPSK, 16-QAM, 64-QAM 802.11b: BPSK, QPSK, CCK

Max Concurrent User

512 Per radio







































Management Features

Multiple BSSID

8 SSIDs on both 2.4GHz, 5GHz and 6GHz bands

VLAN Tagging

Supports 802.1q SSID-to-VLAN Tagging
Cross-Band VLAN Pass-Through
Management VLAN

Spanning Tree

Supports 802.1d Spanning Tree Protocol

QoS (Quality of Service)

Complaint With IEEE 802.11e Standard WMM

SNMP

v1, v2c, v3

MIB

I/II, Private MIB

Fast Roaming

802.11r/k

Wireless Security

WPA2-PSK
WPA2-Enterprise
WPA3-PSK WPA3-Enterprise
Hide SSID in Beacons
Wireless STA (Client) Connected List
Client Isolation

Environmental & Physical

Temperature Range

Operating: 32ºF~104ºF (0 ºC~40 ºC)
Storage: -40 ºF~176 ºF (-40 ºC~80 ºC)

Humidity (non-condensing)

Operating: 90% or less
Storage: 90% or less

Dimensions & Weight

ECW526 Device

Weight: TBD
Width: 190 mm
Length: 190 mm
Height: 39 mm

Package Contents

1 – ECW526 Cloud Managed Indoor Access Point
1 – Ceiling Mount Base
1 – Ceiling and Wall Mount Screw Kit
1 – T-rail Mount kit
1 – Quick Installation Guide

Compliance Regulatory

FCC
CE
IC
UKCA

Warranty

2 Years
