General

• Subtype
  Gigabit Ethernet
• Ports
  24 x 10/100/1000
• Performance
  Switching fabric bandwidth: 160 Gbps
• Jumbo Frame Support
  9216 bytes
• Authentication Method
  Kerberos, RADIUS, Secure Shell (SSH), TACACS+
• Authentication Method
  Kerberos, Secure Shell (SSH), RADIUS, TACACS+
• Status Indicators
  Port status, port transmission speed, port duplex mode, power, system, link/activity
• Routing Protocol
  RIP-1, RIP-2, HSRP, static IP routing, RIPng
• Jumbo Frame Support
  9216 bytes
• Manufacturer
  Cisco

Power Device

• Nominal Voltage
  AC 120/230 V
• Frequency Required
  50/60 Hz
• Type
  internal power supply

Networking

• Cabling Type
  Ethernet 1000Base-T, Ethernet 100Base-TX, Ethernet 10Base-T
• Subcategory
  network hubs and switches
• Subtype
  Gigabit Ethernet
• Form Factor
  rack-mountable
• Type
  Switch
• Connectivity Technology
  wired
• Features
  ARP support, Access Control List (ACL) support, Link Aggregation Control Protocol (LACP), MLD snooping, Multicast Storm Control, Per-VLAN Spanning Tree Plus (PVST+), PoE+, Port Aggregation Protocol (PAgP) support, Quality of Service (QoS), Rapid Spanning Tree Protocol (RSTP) support, Remote Switch Port Analyzer (RSPAN), Shaped Round Robin (SRR), Broadcast Storm Control, Syslog support, Trivial File Transfer Protocol (TFTP) support, Uni-Directional Link Detection (UDLD), Unicast Storm Control, VLAN support, auto-negotiation, auto-uplink (auto MDI/MDI-X), dynamic IP address assignment, hot swap module replacement, layer 2 switching, DHCP snooping, power over Ethernet (PoE), traffic shaping, trunking, DHCP support, Dynamic ARP Inspection (DAI), Dynamic Trunking Protocol (DTP) support, High Availability, IGMP snooping, Jumbo Frames support
• Compliant Standards
  IEEE 802.1D, IEEE 802.1Q, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z, IEEE 802.1ae, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP)
• Jumbo Frame Support
  9216 bytes
• Ports Qty
  24
• Manageable
  Yes
• Routing Protocol
  HSRP, RIP-1, RIP-2, RIPng, static IP routing
• Switching Protocol
  Ethernet
• Remote Management Protocol
  CLI, RMON 1, TFTP, Telnet, RMON 2, RMON 3, RMON 9, SNMP 1, SNMP 2, SNMP 2c, SNMP 3, SSH
• Communication Mode
  full-duplex, half-duplex

Camera

• Installed Size
  128 MB

Interface Provided

• Interface
  Ethernet 10Base-T/100Base-TX, RS-232, console
• Qty
  1, 24
• Connector Type
  RJ-45, mini-USB Type B
• Comments
  management

Power

• Power Redundancy
  optional
• Power Redundancy Scheme
  1+1 (with optional power supply)
• Max Supported Qty
  2
• Features
  Redundant Power System (RPS) connector
• Features
  Redundant Power System (RPS) connector

Miscellaneous

• Compliant Standards
  TUV GS, CISPR 22 Class A, GOST, cUL, NOM, VCCI Class A ITE, EN55022 Class A, CB, AS/NZS 60950-1, AS/NZ 3548 Class A, CCC, RoHS, UL 60950-1, IEC 60950-1, EN 60950-1, KCC, FCC Part 15 A, CSA C22.2 No. 60950-1
• Rack Mounting Kit
  optional
• MTBF
  208218 sec
• Height (Rack Units)
  1 m

RAM

• Installed Size
  256 MB

Environmental Parameters

• Min Storage Temperature
  -40 °F
• Max Storage Temperature
  158 °F
• Min Operating Temperature
  23 °F
• Humidity Range Operating
  5 - 95% (non-condensing)

Header

• Brand
  Cisco
• Product Line
  Cisco Catalyst
• Model
  3560X-24T-S
• Packaged Quantity
  1
• Compatibility
  PC

Dimensions & Weight

• Width
  17.5 in
• Depth
  18.1 in
• Height
  1.8 in
• Weight
  15.43 lbs

Software

• Type
  Cisco IOS IP Base

Ports

• Type
  10/100/1000
• Qty
  24

Expansion Slots

• Type
  expansion slot
• Total Qty
  1
• Free Qty
  1

Performance

• Type
  switching fabric bandwidth
• Value
  160 Gbps

Slot Required

• Type
  none

Capacity

• Type
  virtual interfaces (VLANs)
• Value
  1005

Service & Support

• Type
  limited lifetime warranty

Service & Support Details

• Type
  limited warranty, new releases update
• Full Contract Period
  5 years, lifetime
• Component (Networking)
  power supply and fans

General

• Manufacturer
  Cisco
