Mỹ Thương hiệu: Fortinet

FS-5203B Firewall FortiSwitch Networking blade module for 5000 series

Hàng chính hãng
Giá: Liên hệ
Tình trạng
Hàng chính hãng, có CO CQ đầy đủ
Part Number
FS-5203B Firewall FortiSwitch Networking blade mod
Kho hàng
Liên hệ
Mua nhiều
Khách hàng cần mua số lượng vui lòng liên hệ 0777621381 - 0396827937 để có giá tốt.
Yêu cầu báo giá
Vận chuyển

Giao hàng toàn quốc. Chúng tôi sử dụng các dịch vụ giao hàng và thanh toán tại nhà (COD) của Giaohangtietkiem, Viettel Post, GHN và những dịch vụ khác để giao hàng đến quý khách hàng trong thời gian sớm nhất.

Bán hàng Mr. Đức, Mr. Thành, Mr. Quan, Mr. Thịnh, Mr. Vinh

FS-5203B Firewall FortiSwitch Networking blade module 8x 10 GE SFP+ fabric slots, 2x 10 GE SFP+ base slots, 1x GE RJ45 management port

Module Firewall FortiSwitch FS-5203B bao gồm 8 cổng 10GigE SFP+ fabric slots ( từ cổng F1 đến F8), 2 cổng 10GigE SFP+ base slots ( cổng B1 và B2) hỗ trợ các module quang 10G, 1 cổng 10/100/1000BASE-T (MGMT1) được sử dụng để quản lý.

FS-5203B Firewall FortiSwitch Networking blade module

Physical Description

Interfaces and Modules
40 GE QSFP+ Ports -
10 GE SFP+ Ports 10
GE RJ45 Ports 2
RJ45 Console Port 1
Included Transceivers 2x 10 GE SFP+ SR
Local Storage 64 GB
System Performance and Capacity
Firewall Throughput (1518 / 512 / 64 byte UDP packets) 40 / 40 / 40 Gbps
Firewall Latency (64 byte, UDP) 4 μs
Firewall Throughput (Packet per Second) 60 Mpps
Concurrent Sessions (TCP) 20 Million
New Sessions/Sec (TCP) 170,000
Firewall Policies 200,000
IPsec VPN Throughput (512 byte) 17 Gbps
Gateway-to-Gateway IPsec VPN Tunnels 40,000
Client-to-Gateway IPsec VPN Tunnels 64,000
SSL-VPN Throughput 1.3 Gbps
Concurrent SSL-VPN Users 20,000
IPS Throughput 7.8 Gbps
Virtual Domains (Default / Maximum) 10 / 500
Maximum Number of FortiTokens 5,000
Maximum Number of Registered FortiClients 20,000
Maximum Number of FortiAPs (Total / Tunnel) 4,096 / 1,024
Power and Environment
Power Consumption (Average / Maximum) 210 / 250 W
Heat Dissipation (Average) 853 BTU/h
Operating Temperature 32–104°F (0–40°C)
Storage Temperature -13–158°F (-25–70°C)
Humidity 20–90% non-condensing
Compliance
Certifications FCC Part 15 Class A, C-Tick, VCCI, CE, UL/cUL, CB, ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN
NEBS Certified -

Các loại module quang Fortinet sử dụng được cho module FS-5203B

10 GE SFP+ Transceiver Module, Short Range FG-TRAN-SFP+SR 10 GE SFP+ transceiver module, short range for all systems with SFP+ and SFP/SFP+ slots
10 GE XFP Transceiver Module, Short Range FG-TRAN-XFPSR 10 GE XFP transceiver module, short range for all systems with XFP slots
10 GE SFP+ Transceiver Module, Long Range FG-TRAN-SFP+LR 10 GE SFP+ transceiver module, long range for all systems with SFP+ and SFP/SFP+ slots
10 GE XFP Transceiver Module, Long Range FG-TRAN-XFPLR 10 GE XFP transceiver module, long range for all systems with XFP slots
10 GE SFP+ Active Direct Attach Cable SP-CABLE-ADASFP+ 10 GE SFP+ active direct attach cable, 10m / 32.8 ft for all systems with SFP+ and SFP/SFP+ slots

FS-5203B sử dụng được cho các thiết bị sau

BUNDLE ITEMS  SKU  DESCRIPTION
FortiGate 5144C Chassis FG-5144C-DC 14U 14-slot chassis with 40G Dual Dual Star fabric backplane, 4 PEMs, 4 fan units, 2 shelf FRU data modules, 1 shelf manager, front and RTM air baffles, and 4 pairs DC cables for connecting to FG-5053B power shelves
FortiGate 5144C-DC Chassis FG-5144C-DC-NEBS 14U 14-slot chassis with 40G Dual Dual Star fabric backplane, 4 PEMs, 4 fan units, 2 shelf FRU data modules, 1 shelf manager, front and RTM air baffles, and 4 pairs DC cables for connecting to FG-5053B power shelves, NEBS certified
FortiGate 5140B Chassis FG-5140B-DC 13U 14-slot chassis with 40G Dual Star fabric backplane, 2 PEMs, 4 fan units, 2 shelf FRU data modules, 1 shelf manager, front and RTM air baffles, and 2 pairs DC cables for connecting to FG-5053B power shelves
FortiGate 5060 Chassis FG-5060-DC 5U 6-slot chassis with Dual Star fabric backplane, 2 PEMs, 2 fan units, 2 shelf FRU data modules, 1 shelf manager, front and RTM air baffles, and 2 pairs DC cables for connecting to FG-5053B power shelves

FS-5203B Firewall FortiSwitch Networking blade module 8x 10 GE SFP+ fabric slots, 2x 10 GE SFP+ base slots, 1x GE RJ45 management port

Module Firewall FortiSwitch FS-5203B bao gồm 8 cổng 10GigE SFP+ fabric slots ( từ cổng F1 đến F8), 2 cổng 10GigE SFP+ base slots ( cổng B1 và B2) hỗ trợ các module quang 10G, 1 cổng 10/100/1000BASE-T (MGMT1) được sử dụng để quản lý.

FS-5203B Firewall FortiSwitch Networking blade module

Physical Description

Interfaces and Modules
40 GE QSFP+ Ports -
10 GE SFP+ Ports 10
GE RJ45 Ports 2
RJ45 Console Port 1
Included Transceivers 2x 10 GE SFP+ SR
Local Storage 64 GB
System Performance and Capacity
Firewall Throughput (1518 / 512 / 64 byte UDP packets) 40 / 40 / 40 Gbps
Firewall Latency (64 byte, UDP) 4 μs
Firewall Throughput (Packet per Second) 60 Mpps
Concurrent Sessions (TCP) 20 Million
New Sessions/Sec (TCP) 170,000
Firewall Policies 200,000
IPsec VPN Throughput (512 byte) 17 Gbps
Gateway-to-Gateway IPsec VPN Tunnels 40,000
Client-to-Gateway IPsec VPN Tunnels 64,000
SSL-VPN Throughput 1.3 Gbps
Concurrent SSL-VPN Users 20,000
IPS Throughput 7.8 Gbps
Virtual Domains (Default / Maximum) 10 / 500
Maximum Number of FortiTokens 5,000
Maximum Number of Registered FortiClients 20,000
Maximum Number of FortiAPs (Total / Tunnel) 4,096 / 1,024
Power and Environment
Power Consumption (Average / Maximum) 210 / 250 W
Heat Dissipation (Average) 853 BTU/h
Operating Temperature 32–104°F (0–40°C)
Storage Temperature -13–158°F (-25–70°C)
Humidity 20–90% non-condensing
Compliance
Certifications FCC Part 15 Class A, C-Tick, VCCI, CE, UL/cUL, CB, ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN
NEBS Certified -

Các loại module quang Fortinet sử dụng được cho module FS-5203B

10 GE SFP+ Transceiver Module, Short Range FG-TRAN-SFP+SR 10 GE SFP+ transceiver module, short range for all systems with SFP+ and SFP/SFP+ slots
10 GE XFP Transceiver Module, Short Range FG-TRAN-XFPSR 10 GE XFP transceiver module, short range for all systems with XFP slots
10 GE SFP+ Transceiver Module, Long Range FG-TRAN-SFP+LR 10 GE SFP+ transceiver module, long range for all systems with SFP+ and SFP/SFP+ slots
10 GE XFP Transceiver Module, Long Range FG-TRAN-XFPLR 10 GE XFP transceiver module, long range for all systems with XFP slots
10 GE SFP+ Active Direct Attach Cable SP-CABLE-ADASFP+ 10 GE SFP+ active direct attach cable, 10m / 32.8 ft for all systems with SFP+ and SFP/SFP+ slots

FS-5203B sử dụng được cho các thiết bị sau

BUNDLE ITEMS  SKU  DESCRIPTION
FortiGate 5144C Chassis FG-5144C-DC 14U 14-slot chassis with 40G Dual Dual Star fabric backplane, 4 PEMs, 4 fan units, 2 shelf FRU data modules, 1 shelf manager, front and RTM air baffles, and 4 pairs DC cables for connecting to FG-5053B power shelves
FortiGate 5144C-DC Chassis FG-5144C-DC-NEBS 14U 14-slot chassis with 40G Dual Dual Star fabric backplane, 4 PEMs, 4 fan units, 2 shelf FRU data modules, 1 shelf manager, front and RTM air baffles, and 4 pairs DC cables for connecting to FG-5053B power shelves, NEBS certified
FortiGate 5140B Chassis FG-5140B-DC 13U 14-slot chassis with 40G Dual Star fabric backplane, 2 PEMs, 4 fan units, 2 shelf FRU data modules, 1 shelf manager, front and RTM air baffles, and 2 pairs DC cables for connecting to FG-5053B power shelves
FortiGate 5060 Chassis FG-5060-DC 5U 6-slot chassis with Dual Star fabric backplane, 2 PEMs, 2 fan units, 2 shelf FRU data modules, 1 shelf manager, front and RTM air baffles, and 2 pairs DC cables for connecting to FG-5053B power shelves

Giao hàng toàn quốc. Chúng tôi sử dụng các dịch vụ giao hàng và thanh toán tại nhà (COD) của Giaohangtietkiem, Viettel Post, GHN và những dịch vụ khác để giao hàng đến quý khách hàng trong thời gian sớm nhất.
