Phatsongwifi
Mỹ Thương hiệu: Fortinet

Firewall FortiGate FG-80F-POE 8 x GE PoE ports, 2 x RJ45/SFP

Hàng chính hãng
Giá: Liên hệ
Tình trạng
Hàng chính hãng, có CO CQ đầy đủ
Part Number
Firewall FortiGate FG-80F-POE 8 x GE PoE ports, 2
Kho hàng
Liên hệ
Mua nhiều
Khách hàng cần mua số lượng vui lòng liên hệ 0777621381 - 0396827937 để có giá tốt.
Yêu cầu báo giá
Vận chuyển

Giao hàng toàn quốc. Chúng tôi sử dụng các dịch vụ giao hàng và thanh toán tại nhà (COD) của Giaohangtietkiem, Viettel Post, GHN và những dịch vụ khác để giao hàng đến quý khách hàng trong thời gian sớm nhất.

Bán hàng Mr. Đức, Mr. Thành, Mr. Quan, Mr. Thịnh, Mr. Vinh

Firewall FortiGate FG-80F-POE

Thông số kỹ thuật Specifications

Datasheet FortiGate FG-80F-POE
GE RJ45/SFP Shared Media Pairs 2
GE RJ45 PoE/+ Ports 6
GE RJ45 PoE/+ FortiLink Ports (Default) 2
USB Ports 3.0 1
Console (RJ45) 1
Trusted Platform Module (TPM) 1
Bluetooth Low Energy (BLE) 1
IPS Throughput 1.4 Gbps
NGFW Throughput 1 Gbps
Threat Protection Throughput 900 Mbps
System Performance
Firewall Throughput (1518 / 512 / 64 byte UDP packets) 10/10/7 Gbps
Firewall Latency (64 byte UDP packets) 3.23 μs
Firewall Throughput (Packets Per Second) 10.5 Mpps
Concurrent Sessions (TCP) 1.5 Million
New Sessions/Second (TCP) 45 000
Firewall Policies 5000
IPsec VPN Throughput (512 byte) 6.5 Gbps
Gateway-to-Gateway IPsec VPN Tunnels 200
Client-to-Gateway IPsec VPN Tunnels 2500
SSL-VPN Throughput 950 Mbps
Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) 200
SSL Inspection Throughput (IPS, avg. HTTPS) 715 Mbps
SSL Inspection CPS (IPS, avg. HTTPS) 700
SSL Inspection Concurrent Session (IPS, avg. HTTPS) 100 000
Application Control Throughput (HTTP 64K) 1.8 Gbps
CAPWAP Throughput (HTTP 64K) 9 Gbps
Virtual Domains (Default / Maximum) 10 / 10
Maximum Number of FortiSwitches Supported 16
Maximum Number of FortiAPs (Total / Tunnel Mode) 96 / 48
Maximum Number of FortiTokens 500
High Availability Configurations Active-Active, Active-Passive, Clustering
Dimensions
Height x Width x Length (inches) 2.4 x 8.5 x 7.0
Height x Width x Length (mm) 60 x 216 x 178
Weight 3.1 lbs (1.4 kg)
Operating Environment and Certifications
Input Rating +54V DC, 3A (dual redundancy optional)
Power Required (Redundancy Optional) Powered by up to 2 External DC Power Adapters (1 adapter included), 100–240V AC, 50/60 Hz
Maximum Current 115VAC/2.2A, 230VAC/1.1A
Total Available PoE Power Budget 96W
Power Consumption (Average / Maximum) 96W / 118W
Heat Dissipation 402.26 BTU/h
402.26 BTU/h 32–104°F (0–40°C)
Storage Temperature -31–158°F (-35–70°C)
Humidity 10–90% non-condensing
Noise Level 31.56 dBA
Operating Altitude Up to 7400 ft (2250 m)
Compliance FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB
Certifications ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN

Firewall FortiGate FG-80F-POE

Thông số kỹ thuật Specifications

Datasheet FortiGate FG-80F-POE
GE RJ45/SFP Shared Media Pairs 2
GE RJ45 PoE/+ Ports 6
GE RJ45 PoE/+ FortiLink Ports (Default) 2
USB Ports 3.0 1
Console (RJ45) 1
Trusted Platform Module (TPM) 1
Bluetooth Low Energy (BLE) 1
IPS Throughput 1.4 Gbps
NGFW Throughput 1 Gbps
Threat Protection Throughput 900 Mbps
System Performance
Firewall Throughput (1518 / 512 / 64 byte UDP packets) 10/10/7 Gbps
Firewall Latency (64 byte UDP packets) 3.23 μs
Firewall Throughput (Packets Per Second) 10.5 Mpps
Concurrent Sessions (TCP) 1.5 Million
New Sessions/Second (TCP) 45 000
Firewall Policies 5000
IPsec VPN Throughput (512 byte) 6.5 Gbps
Gateway-to-Gateway IPsec VPN Tunnels 200
Client-to-Gateway IPsec VPN Tunnels 2500
SSL-VPN Throughput 950 Mbps
Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) 200
SSL Inspection Throughput (IPS, avg. HTTPS) 715 Mbps
SSL Inspection CPS (IPS, avg. HTTPS) 700
SSL Inspection Concurrent Session (IPS, avg. HTTPS) 100 000
Application Control Throughput (HTTP 64K) 1.8 Gbps
CAPWAP Throughput (HTTP 64K) 9 Gbps
Virtual Domains (Default / Maximum) 10 / 10
Maximum Number of FortiSwitches Supported 16
Maximum Number of FortiAPs (Total / Tunnel Mode) 96 / 48
Maximum Number of FortiTokens 500
High Availability Configurations Active-Active, Active-Passive, Clustering
Dimensions
Height x Width x Length (inches) 2.4 x 8.5 x 7.0
Height x Width x Length (mm) 60 x 216 x 178
Weight 3.1 lbs (1.4 kg)
Operating Environment and Certifications
Input Rating +54V DC, 3A (dual redundancy optional)
Power Required (Redundancy Optional) Powered by up to 2 External DC Power Adapters (1 adapter included), 100–240V AC, 50/60 Hz
Maximum Current 115VAC/2.2A, 230VAC/1.1A
Total Available PoE Power Budget 96W
Power Consumption (Average / Maximum) 96W / 118W
Heat Dissipation 402.26 BTU/h
402.26 BTU/h 32–104°F (0–40°C)
Storage Temperature -31–158°F (-35–70°C)
Humidity 10–90% non-condensing
Noise Level 31.56 dBA
Operating Altitude Up to 7400 ft (2250 m)
Compliance FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB
Certifications ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN
