Phatsongwifi
Mỹ Thương hiệu: Fortinet

FG-5001E Firewall Fortigate Security blade module for 5000 series

Hàng chính hãng
Giá: Liên hệ
Tình trạng
Hàng chính hãng, có CO CQ đầy đủ
Part Number
FG-5001E Firewall Fortigate Security blade module
Kho hàng
Liên hệ
Mua nhiều
Khách hàng cần mua số lượng vui lòng liên hệ 0777621381 - 0396827937 để có giá tốt.
Yêu cầu báo giá
Vận chuyển

Giao hàng toàn quốc. Chúng tôi sử dụng các dịch vụ giao hàng và thanh toán tại nhà (COD) của Giaohangtietkiem, Viettel Post, GHN và những dịch vụ khác để giao hàng đến quý khách hàng trong thời gian sớm nhất.

Bán hàng Mr. Đức, Mr. Thành, Mr. Quan, Mr. Thịnh, Mr. Vinh

FG-5001E Firewall Fortigate Security blade module 2x 40 GE QSFP+ ports, 2x 10 GE SFP+, 2x GE RJ45 management, FortiASIC NP6 and CP9 hardware accelerated

Module Firewall Fortigate FG-5001E bao gồm 2 cổng 40GigE QSFP+ ( cổng 1 và 2). Các cổng này cung cấp tốc độ 40 gigabit ethernet tới module xử lý FPM, Hai cổng 10GigE SFP+ (cổng 3 và 4) hỗ trợ các module quang 10G, 2 cổng 10/100/1000BASE-T (MGMT1, MGMT2) được sử dụng để quản lý.

FG-5001E Firewall Fortigate Security blade module

Physical Description

Interfaces and Modules
40 GE QSFP+ Ports 2
10 GE SFP+ Ports 2
GE RJ45 Ports 2
RJ45 Console Port 1
Included Transceivers 2x 10 GE SFP+ SR
Local Storage -
System Performance and Capacity
Firewall Throughput (1518 / 512 / 64 byte UDP packets) 80 / 80 / 50 Gbps
Firewall Latency (64 byte, UDP) 3 μs
Firewall Throughput (Packet per Second) 75 Mpps
Concurrent Sessions (TCP) 40 Million
New Sessions/Sec (TCP) 640,000
Firewall Policies 200,000
IPsec VPN Throughput (512 byte) 45 Gbps
Gateway-to-Gateway IPsec VPN Tunnels 40,000
Client-to-Gateway IPsec VPN Tunnels 64,000
SSL-VPN Throughput 9 Gbps
Concurrent SSL-VPN Users 25,000
SSL Inspection Throughput 17 Gbps
SSL Inspection Throughput (IPS, HTTP) 25 / 18 Gbps
Application Control Throughput 36 Gbps
NGFW Throughput 15 Gbps
Threat Protection Throughput 13.5 Gbps
CAPWAP Throughput (1444 byte, UDP) 15 Gbps
Virtual Domains (Default / Maximum) 10 / 500
Maximum Number of FortiTokens 5,000
Maximum Number of Registered FortiClients 20,000
Maximum Number of FortiAPs (Total / Tunnel) 4,096 / 1,024
Power and Environment
Power Consumption (Average / Maximum) 250 / 278 W
Heat Dissipation (Average) 948.6 BTU/h
Operating Temperature 23–131°F (-5–55°C)
Storage Temperature -40–158°F (-40–70°C)
Humidity 10–90% non-condensing
Compliance
Certifications FCC Part 15 Class A, C-Tick, VCCI, CE, UL/cUL, CB, ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN
NEBS Certified -

Các loại module quang Fortinet sử dụng được cho module FG-5001E

10 GE SFP+ Transceiver Module, Short Range FG-TRAN-SFP+SR 10 GE SFP+ transceiver module, short range for all systems with SFP+ and SFP/SFP+ slots
10 GE XFP Transceiver Module, Short Range FG-TRAN-XFPSR 10 GE XFP transceiver module, short range for all systems with XFP slots
10 GE SFP+ Transceiver Module, Long Range FG-TRAN-SFP+LR 10 GE SFP+ transceiver module, long range for all systems with SFP+ and SFP/SFP+ slots
10 GE XFP Transceiver Module, Long Range FG-TRAN-XFPLR 10 GE XFP transceiver module, long range for all systems with XFP slots
40 GE QSFP+ Transceivers, Short Range FG-TRAN-QSFP+SR 40 GE QSFP+ transceivers, short range for all systems with QSFP+ slots
10 GE SFP+ Active Direct Attach Cable SP-CABLE-ADASFP+ 10 GE SFP+ active direct attach cable, 10m / 32.8 ft for all systems with SFP+ and SFP/SFP+ slots

FG-5001E sử dụng được cho các thiết bị sau

BUNDLE ITEMS  SKU  DESCRIPTION
FortiGate 5144C Chassis FG-5144C-DC 14U 14-slot chassis with 40G Dual Dual Star fabric backplane, 4 PEMs, 4 fan units, 2 shelf FRU data modules, 1 shelf manager, front and RTM air baffles, and 4 pairs DC cables for connecting to FG-5053B power shelves
FortiGate 5144C-DC Chassis FG-5144C-DC-NEBS 14U 14-slot chassis with 40G Dual Dual Star fabric backplane, 4 PEMs, 4 fan units, 2 shelf FRU data modules, 1 shelf manager, front and RTM air baffles, and 4 pairs DC cables for connecting to FG-5053B power shelves, NEBS certified
FortiGate 5140B Chassis FG-5140B-DC 13U 14-slot chassis with 40G Dual Star fabric backplane, 2 PEMs, 4 fan units, 2 shelf FRU data modules, 1 shelf manager, front and RTM air baffles, and 2 pairs DC cables for connecting to FG-5053B power shelves
FortiGate 5060 Chassis FG-5060-DC 5U 6-slot chassis with Dual Star fabric backplane, 2 PEMs, 2 fan units, 2 shelf FRU data modules, 1 shelf manager, front and RTM air baffles, and 2 pairs DC cables for connecting to FG-5053B power shelves

FG-5001E Firewall Fortigate Security blade module 2x 40 GE QSFP+ ports, 2x 10 GE SFP+, 2x GE RJ45 management, FortiASIC NP6 and CP9 hardware accelerated

Module Firewall Fortigate FG-5001E bao gồm 2 cổng 40GigE QSFP+ ( cổng 1 và 2). Các cổng này cung cấp tốc độ 40 gigabit ethernet tới module xử lý FPM, Hai cổng 10GigE SFP+ (cổng 3 và 4) hỗ trợ các module quang 10G, 2 cổng 10/100/1000BASE-T (MGMT1, MGMT2) được sử dụng để quản lý.

FG-5001E Firewall Fortigate Security blade module

Physical Description

Interfaces and Modules
40 GE QSFP+ Ports 2
10 GE SFP+ Ports 2
GE RJ45 Ports 2
RJ45 Console Port 1
Included Transceivers 2x 10 GE SFP+ SR
Local Storage -
System Performance and Capacity
Firewall Throughput (1518 / 512 / 64 byte UDP packets) 80 / 80 / 50 Gbps
Firewall Latency (64 byte, UDP) 3 μs
Firewall Throughput (Packet per Second) 75 Mpps
Concurrent Sessions (TCP) 40 Million
New Sessions/Sec (TCP) 640,000
Firewall Policies 200,000
IPsec VPN Throughput (512 byte) 45 Gbps
Gateway-to-Gateway IPsec VPN Tunnels 40,000
Client-to-Gateway IPsec VPN Tunnels 64,000
SSL-VPN Throughput 9 Gbps
Concurrent SSL-VPN Users 25,000
SSL Inspection Throughput 17 Gbps
SSL Inspection Throughput (IPS, HTTP) 25 / 18 Gbps
Application Control Throughput 36 Gbps
NGFW Throughput 15 Gbps
Threat Protection Throughput 13.5 Gbps
CAPWAP Throughput (1444 byte, UDP) 15 Gbps
Virtual Domains (Default / Maximum) 10 / 500
Maximum Number of FortiTokens 5,000
Maximum Number of Registered FortiClients 20,000
Maximum Number of FortiAPs (Total / Tunnel) 4,096 / 1,024
Power and Environment
Power Consumption (Average / Maximum) 250 / 278 W
Heat Dissipation (Average) 948.6 BTU/h
Operating Temperature 23–131°F (-5–55°C)
Storage Temperature -40–158°F (-40–70°C)
Humidity 10–90% non-condensing
Compliance
Certifications FCC Part 15 Class A, C-Tick, VCCI, CE, UL/cUL, CB, ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN
NEBS Certified -

Các loại module quang Fortinet sử dụng được cho module FG-5001E

10 GE SFP+ Transceiver Module, Short Range FG-TRAN-SFP+SR 10 GE SFP+ transceiver module, short range for all systems with SFP+ and SFP/SFP+ slots
10 GE XFP Transceiver Module, Short Range FG-TRAN-XFPSR 10 GE XFP transceiver module, short range for all systems with XFP slots
10 GE SFP+ Transceiver Module, Long Range FG-TRAN-SFP+LR 10 GE SFP+ transceiver module, long range for all systems with SFP+ and SFP/SFP+ slots
10 GE XFP Transceiver Module, Long Range FG-TRAN-XFPLR 10 GE XFP transceiver module, long range for all systems with XFP slots
40 GE QSFP+ Transceivers, Short Range FG-TRAN-QSFP+SR 40 GE QSFP+ transceivers, short range for all systems with QSFP+ slots
10 GE SFP+ Active Direct Attach Cable SP-CABLE-ADASFP+ 10 GE SFP+ active direct attach cable, 10m / 32.8 ft for all systems with SFP+ and SFP/SFP+ slots

FG-5001E sử dụng được cho các thiết bị sau

BUNDLE ITEMS  SKU  DESCRIPTION
FortiGate 5144C Chassis FG-5144C-DC 14U 14-slot chassis with 40G Dual Dual Star fabric backplane, 4 PEMs, 4 fan units, 2 shelf FRU data modules, 1 shelf manager, front and RTM air baffles, and 4 pairs DC cables for connecting to FG-5053B power shelves
FortiGate 5144C-DC Chassis FG-5144C-DC-NEBS 14U 14-slot chassis with 40G Dual Dual Star fabric backplane, 4 PEMs, 4 fan units, 2 shelf FRU data modules, 1 shelf manager, front and RTM air baffles, and 4 pairs DC cables for connecting to FG-5053B power shelves, NEBS certified
FortiGate 5140B Chassis FG-5140B-DC 13U 14-slot chassis with 40G Dual Star fabric backplane, 2 PEMs, 4 fan units, 2 shelf FRU data modules, 1 shelf manager, front and RTM air baffles, and 2 pairs DC cables for connecting to FG-5053B power shelves
FortiGate 5060 Chassis FG-5060-DC 5U 6-slot chassis with Dual Star fabric backplane, 2 PEMs, 2 fan units, 2 shelf FRU data modules, 1 shelf manager, front and RTM air baffles, and 2 pairs DC cables for connecting to FG-5053B power shelves

Giao hàng toàn quốc. Chúng tôi sử dụng các dịch vụ giao hàng và thanh toán tại nhà (COD) của Giaohangtietkiem, Viettel Post, GHN và những dịch vụ khác để giao hàng đến quý khách hàng trong thời gian sớm nhất.
