Firebox M590 and M690 firewalls are specifically engineered for midsize and distributed enterprises that are struggling to effectively and affordably secure networks in the face of explosive growth in bandwidth rates, encrypted traffic, video use, and connection speeds. With an operating system built on the latest multi-core processors the M590 and M690 have all the power they need to run their security scanning engines in parallel, without causing a bottleneck in performance.
Firebox M590 and M690 firewalls are specifically engineered for midsize and distributed enterprises that are struggling to effectively and affordably secure networks in the face of explosive growth in bandwidth rates, encrypted traffic, video use, and connection speeds. With an operating system built on the latest multi-core processors the M590 and M690 have all the power they need to run their security scanning engines in parallel, without causing a bottleneck in performance.
Giao hàng toàn quốc. Chúng tôi sử dụng các dịch vụ giao hàng và thanh toán tại nhà (COD) của Giaohangtietkiem, Viettel Post, GHN và những dịch vụ khác để giao hàng đến quý khách hàng trong thời gian sớm nhất.
Firebox M590 and M690 firewalls are specifically engineered for midsize and distributed enterprises that are struggling to effectively and affordably secure networks in the face of explosive growth in bandwidth rates, encrypted traffic, video use, and connection speeds. With an operating system built on the latest multi-core processors the M590 and M690 have all the power they need to run their security scanning engines in parallel, without causing a bottleneck in performance.
WatchGuard Cloud provides full visibility into your network so that you can make timely, informed, and effective decisions about your network security anywhere, anytime. The platform displays 100+ dashboards and reports that allow you to quickly see high-level trends and anomalies, then drill down into detailed information on each.
The Firebox M Series provides empty bays that can be used to add network modules to define a configuration that meet the needs of almost any network configuration. Each appliance has an open module bay for expansion modules, with options for 8 x 1 Gb copper, 4 x 1 Gb copper, 4 x 1 SFP, 2 x 1 SFP+, or 4 port multispeed ports. Network modularity empowers IT pros to customize the port configuration to meet their needs, while ensuring the flexibility to adapt the firewall as their network evolves.
Firebox M590 and M690 can be equipped with a 4 port multispeed POE+ module that eliminates the need to have separate power running to peripheral devices. POE+ ports simplify the process of powering other devices, like security cameras or WatchGuard’s USP Wi-Fi Access Points.
High availability ensures maximum uptime. Buy two M590 or M690 for an active/passive high availability pair and receive 50% off the cost of the second device.
Outstanding performance with up to 29.7 Gbps firewall throughput and 4.6 Gbps throughput with full Total Security Services running.
Take advantage of innovative features like simplified VPN creation in WatchGuard Cloud to make fast work of extending your network.
Optional 8 x 1 Gb copper, 4 x 1 Gb copper, 4 x 1 SFP, 2 x 1 SFP+, or 4 port multispeed POE+ ports
Firebox | M590 | M690 |
---|---|---|
Throughput | ||
UTM (full scan) | 3.3 Gbps | 4.6 Gbps |
VPN (IMIX) | 2.2 Gbps | 3.2 Gbps |
HTTPS (IPS enabled) | 1.9 Gbps | 2.9 Gbps |
AntiVirus | 5.0 Gbps | 6.2 Gbps |
IPS (full scan) | 4.6 Gbps | 5.8 Gbps |
Firewall (UDP 1518) | 20 Gbps | 29.7 Gbps |
VPN (UDP 1518) | 6.8 Gbps | 10.0 Gbps |
Capacity | ||
Interfaces 10/100/1000 | 8x1Gb & 2xSFP+ | 8x1Gb & 2xSFP+ & 2x10Gb multispeed |
I/O interfaces | 1 serial/2 USB | 1 serial/2 USB |
Concurrent connections | 6,000,000 | 15,000,000 |
New connections per second | 132,000 | 146,000 |
VLANs | 750 | 1,000 |
WSM licenses (incl) | 4 | 4 |
TDR Host Sensors included | 250 | 250 |
VPN Tunnels | ||
Branch Office VPN | 500 | 1,000 |
Mobile VPN | 500 | 1,000 |
Security Features | ||
Firewall | Stateful packet inspection, deep packet inspection, proxy firewall | |
Application proxies | HTTP, HTTPS, FTP, DNS, TCP/UDP, POP3, SMTP, IMAPS, POP3S and Explicit Proxy | |
Threat protection | DoS attacks, fragmented & malformed packets, blended threats | |
Filtering options | Browser Safe Search, Google for Business | |
VPN | ||
Site to Site VPN | KEv2, IPSec, Policy and Route Based Tunnels, TLS hub and spoke | |
Remote Access VPN | KEv2, IPSec, L2TP, TLS | |
Visibility | ||
Logging and notifications | WatchGuard Cloud & Dimension, Syslog, SNMP v2/v3 | |
Reporting | WatchGuard Cloud includes over 100 pre-defined reports, executive summary and visibility tools | |
Certifications | ||
Security* | Pending: Common Criteria, FIPS 140-3 | |
Safety | NRTL/C, CB | |
Network | IPv6 Ready Gold (routing) | |
Hazardous substance control | WEEE, RoHS, REACH | |
Networking | ||
SD-WAN | Multi-WAN failover, dynamic path selection, jitter/loss/latency measurement | |
Dynamic Routing | RIP, OSPF, BGP | |
High Availability | Active/passive, active/active | |
QoS | 802.1Q, DSCP, IP Precedence | |
Traffic Management | By policy or application | |
IP address assignment | Static, DHCP (server, client, relay), PPPoE, DynDNS | |
NAT | Static, dynamic, 1:1, IPSec traversal, policy-based | |
Link aggregation | 802.3ad dynamic, static, active/backup | |
Physical and Environment | M590 | M690 |
Physical and Power Specifications | ||
Product Dimensions | 12.08” x 17.24” x 1.73”(307 mm X 438 mm x 44 mm) | 12.08” x 17.24” x 1.73”(307 mm X 438 mm x 44 mm) |
Shipping Dimensions | 22.71” x 8.14” x 17.44” (588 mm x 648 mm x 200 mm) | 22.71” x 8.14” x 17.44” (588 mm x 648 mm x 200 mm) |
Shipping Weight | 14.33 lbs (6.5 kg) | 14.33 lbs (6.5 kg) |
Power | Dual PSU -150W, G0937-120-1250-1, 90-264VAC~, 2.2A/2.4A, 47-63Hz | |
Power Consumption | 110V AC power: 75W at 45°C at 54% fan speed | 110V AC power: 87W at 45°C at 66% fan speed |
MTBF | 443,771 hours | 337,443 hours |
Environment Specifications | ||
Operating Temperature | 32° F to 104° F / 0° C to 40° C | |
Storage Temperature | -40° F to 158° F / -40° C to 70° C | |
Operating Relative Humidity | 5% to 90% non-condensing | |
Storage Relative Humidity | 5% to 90% non-condensing | |
Operating Altitude | 0 to 9,843 ft at 95° F (3,000 m at 35° C) | |
Storage Altitude | 0 to 15,000 ft at 95° F (4,570 m at 35° C) |
Firebox M590 and M690 firewalls are specifically engineered for midsize and distributed enterprises that are struggling to effectively and affordably secure networks in the face of explosive growth in bandwidth rates, encrypted traffic, video use, and connection speeds. With an operating system built on the latest multi-core processors the M590 and M690 have all the power they need to run their security scanning engines in parallel, without causing a bottleneck in performance.
WatchGuard Cloud provides full visibility into your network so that you can make timely, informed, and effective decisions about your network security anywhere, anytime. The platform displays 100+ dashboards and reports that allow you to quickly see high-level trends and anomalies, then drill down into detailed information on each.
The Firebox M Series provides empty bays that can be used to add network modules to define a configuration that meet the needs of almost any network configuration. Each appliance has an open module bay for expansion modules, with options for 8 x 1 Gb copper, 4 x 1 Gb copper, 4 x 1 SFP, 2 x 1 SFP+, or 4 port multispeed ports. Network modularity empowers IT pros to customize the port configuration to meet their needs, while ensuring the flexibility to adapt the firewall as their network evolves.
Firebox M590 and M690 can be equipped with a 4 port multispeed POE+ module that eliminates the need to have separate power running to peripheral devices. POE+ ports simplify the process of powering other devices, like security cameras or WatchGuard’s USP Wi-Fi Access Points.
High availability ensures maximum uptime. Buy two M590 or M690 for an active/passive high availability pair and receive 50% off the cost of the second device.
Outstanding performance with up to 29.7 Gbps firewall throughput and 4.6 Gbps throughput with full Total Security Services running.
Take advantage of innovative features like simplified VPN creation in WatchGuard Cloud to make fast work of extending your network.
Optional 8 x 1 Gb copper, 4 x 1 Gb copper, 4 x 1 SFP, 2 x 1 SFP+, or 4 port multispeed POE+ ports
