Category 6A, low smoke zero halogen (LSZH), 4-pair, U/UTP copper cable. Blue color
Category 6A, low smoke zero halogen (LSZH), 4-pair, U/UTP copper cable. Blue color
Giao hàng toàn quốc. Chúng tôi sử dụng các dịch vụ giao hàng và thanh toán tại nhà (COD) của Giaohangtietkiem, Viettel Post, GHN và những dịch vụ khác để giao hàng đến quý khách hàng trong thời gian sớm nhất.
The NetKey™ Cat 6A U/UTP copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The conductors are twisted in pairs with an alien crosstalk barrier. All four pairs are surrounded by a HDPE flame-retardant jacket. The blue, LSZH (IEC 60332-1, EuroClass Dca-s2,d2,a1) cable is supplied 305 meters (1,000 feet) to a reel.
Note | Available in EMEA |
Environment | Indoor |
Performance Level | Category 6A |
Cable Construction | U/UTP |
Flammability Rating | LSZH (IEC 60332-1) |
EuroClass Rating | Dca-s2,d2,a1 |
LP Rating | NA |
Resistance Properties | Flame Retardant |
Jacket Material | LSZH |
Nominal Cable Outside Diameter (In.) | 0.283 |
Nominal Cable Outside Diameter (mm) | 7.2 |
Maximum Operating Temperature (°C) | 60 |
Maximum Operating Temperature (°F) | 140 |
Minimum Operating Temperature (°C) | -20 |
Minimum Operating Temperature (°F) | -4 |
Maximum Installation Temperature (°C) | 50 |
Maximum Installation Temperature (°F) | 122 |
Minimum Installation Temperature (°C) | 0 |
Minimum Installation Temperature (°F) | 32 |
Sub Brand | NetKey® |
Maximum Installation Tension (lb) | 25 |
Maximum Installation Tension (N) | 110 |
Bend Radius (In.) | 2.27 |
Bend Radius (mm) | 57 |
Number of Pairs | 4 |
Conductor Material | Copper |
Conductor Type | Solid |
Overall Length (m) | 305 |
Conductor Gauge (AWG) | 23 |
Insulation Material | NA |
Acidity Rating | a1 |
Insulation Diameter (In.) | 0.047 |
Insulation Diameter (mm) | 1.2 |
Maximum Voltage (V) | 80 |
Standards Met | Exceeds ISO 11801 Class EA and ANSI/TIA-568.2-D Category 6A, IEC 61156-5, IEC 60332-1, IEC 60754, IEC 61034, EN 50575: Euroclass Dca-s2-d2-a1, meets IEEE 802.3af, IEEE 802.3at and IEEE 802.3bt for PoE applications, RoHS Compliant. |
Color | Blue |
Flaming Droplets Rating | d2 |
Overall Length (ft.) | 1000 |
Packaging Type | Reel |
Product Type | Copper Cable |
Smoke Rating | s2 |
EuroClass Flame Rating | Dca |
